APPENDIX 2: Installation details: configuration of ARENA consoles and BC2000D
matrices for use with AoIP multichannel boards.
A2.1. Scope.
The purpose of this appendix is to detail the default nomenclature of audio channels in ARENA
consoles and BC2000D matrices in order to ease installation and configuration of a
multichannel AoIP audio system.
A2.1.1. ARENA, BC2000D and DANTE internal systems correspondence.
Have in mind that the configuration of the input and output channels in the internal configuration
menus and configuration software for ARENA consoles and BC2000D matrices is not
transferred to the channels that appears in "Dante Controller" application, so both systems must
be configured separately. Also note that:
• DANTE identifies stereo lines as dual mono, so different names are assigned to left and
right channels forming stereo line. Therefore, stereo lines must be managed as dual
mono lines.
• ARENA displays support only up to 7 characters per normal label and up to 4 per short
label.
• BC2000D matrices configuration software has a "wizard" in order to create the lines
names automatically.
• The name of the internal bus or input routed to an output is sometimes more meaningful
than the output line name itself.
The names that are associated by default to input/output lines of BC2214 boards in ARENA
consoles and BC2000D matrices and to associated channels that appears in "Dante Controller"
are detailed next, in order to ease a coherent configuration for both systems and the routing
between them.
ARENA console.
Inputs
Labels in ARENA
Inputs
Short labels in ARENA
Reception channels
Labels in DANTE Controller
AOIP01 IP01 BC2214_1L
BC2214_1R
AOIP02 IP02 BC2214_2L
BC2214_2R
AOIP03 IP03 BC2214_3L
BC2214_3R
AOIP04 IP04 BC2214_4L
BC2214_4R
AOIP05 IP05 BC2214_5L
BC2214_6R
AOIP06 IP06 BC2214_6L
BC2214_7R
AOIP07 IP07 BC2214_7L
BC2214_8R
AOIP08 IP08 BC2214_8L
BC2214_8R
AOIP09 IP09 BC2214_9L
BC2214_9R
AOIP10 IP10 BC2214_10L
BC2214_10R
AOIP11 IP11 BC2214_11L
BC2214_11R
AOIP12 IP12 BC2214_12L
BC2214_12R
AOIP13 IP13 BC2214_13L
BC2214_13R
AOIP14 IP14 BC2214_14L
BC2214_14R
