AEQ Audio Over IP
Routing System
112
APPENDIX 3: Installation details: configuration of FORUM and CAPITOL IP consoles for
use with AoIP multichannel boards.
A3.1. Scope.
The purpose of this appendix is to review and set the information of the FORUM and CAPITOL
digital mixing consoles User Manuals in order to ease installation and configuration of a
multichannel AoIP audio system.
All the important adjustments required to configure inputs, outputs, assign faders and other
important issues (regarding internal routing in the equipment to integrate it into a multichannel
system) are reviewed below on the configuration software and the physical unit display screens.
A3.1.1. FORUM, CAPITOL and DANTE internal systems correspondence.
Have in mind that the configuration of the input and output channels in the internal configuration
menus and configuration software for FORUM and CAPITOL IP consoles is not transferred to
the channels that appears in "Dante Controller" application, so both systems must be configured
separately. Also note that:
• DANTE identifies stereo lines as dual mono, so different names are assigned to left and
right channels forming stereo line. Therefore, stereo lines must be managed as dual
mono lines.
• FORUM and CAPITOL IP displays support only up to 6 characters per label.
• The name of the internal bus or input routed to an output is sometimes more meaningful
than the output line name itself.
The names that are associated by default to input/output lines of AoIP boards in FORUM and
CAPITOL IP consoles and to associated channels that appears in "Dante Controller" are
detailed next, in order to ease a coherent configuration for both systems and the routing
between them.
FORUM console.
Inputs
Labels in FORUM
Reception channels
Labels in DANTE Controller
AOIP01 FORUM_1L
FORUM _1R
AOIP02 FORUM _2L
FORUM _2R
AOIP03 FORUM _3L
FORUM _3R
AOIP04 FORUM _4L
FORUM _4R
AOIP05 FORUM _5L
FORUM _5R
AOIP06 FORUM _6L
FORUM _6R
AOIP07 FORUM _7L
FORUM _7R
AOIP08 FORUM _8L
FORUM _8R
AOIP09 FORUM _9L
FORUM _9R
AOIP10 FORUM _10L
FORUM _10R
AOIP11 FORUM _11L
FORUM _11R
AOIP12 FORUM _12L
FORUM _12R
AOIP13 FORUM _13L
FORUM _13R
