42
DE
GND GND
3. ANSCHLUSS AN FCWI
3.1. PHASE 1 - Elektrische Anschlüsse
Vorheriger Knoten
VMF-Netz
Nächster Knoten
VMF-Netz
Vin: 230 Vac
50/60 Hz
Imax: 0.15 A
HINWEIS: Vor weiteren Schritten sicherstellen, dass
die DIP-Schalter richtig konfiguriert sind:
SW1
DIP 1 DIP 2 DIP 3 DIP 4
OFF OFF OFF ---
