6
IT
GND GND
3. COLLEGAMENTO CON FCWI
3.1. FASE 1 - Collegamenti elettrici
Nodo precedente
rete VMF
Nodo successivo
rete VMF
Vin: 230 Vac
50/60 Hz
Imax: 0.15 A
NOTA: prima di procede oltre assicurarsi che i
dipswitches SW1 siano correttamente configurati:
SW1
DIP 1 DIP 2 DIP 3 DIP 4
OFF OFF OFF ---
