3.4. FCWI/VMF-485LINK overview
FCWI (n)
FCWI (1)
VMF-485LINK (1)
VMF-485LINK (n)
VMF-E6
A B
A
B
B
A 3-pole serial cable + shield
B 3-pole serial cable + shield
NB:
Each FCWI unit is equalized to a MASTER fan coil on the VMF network, however additional SLAVES
cannot be connected to this!however, it will be possible to have several zones equipped and addressed
with FCWI units properly connected and addressed through the procedure indicated above.
