AERMEC WRC40 - Vertical Swing Fin Adjustment; Horizontal Swing Fin Adjustment

13
SETTING THE VERTICAL MOTORISED
DISCHARGE FIN UP&DOWN SWING
SETTING THE HORIZONTAL MOTORISED
DISCHARGE FIN LEFT&RIGHT SWING
Setting the swing
If the unit is on, while pressing the button
MENU/OK
FAN
ON/OFF
MODE
SWING
it
activates the swing of the motorized supply air fin
(UP&DOWN). The fin allows to change the air flow in
the room depending on the set position; the logic
where this function is managed:
When the unit is on, while pressing the button it’s
possible to set one by one the following steps:
SWING
disabled
SWING
disabled
If the unit is on, while pressing the button
MENU/OK
FAN
ON/OFF
MODE
SWING
it
activates the swing of the motorized supply air fin
(LEFT&RIGHT). The fin allows to change the air flow
in the room depending on the set position; the logic
where this function is managed:
When the unit is on, while pressing the button it’s
possible to set one by one the following steps:
