Notes for installing the wired panel.
It’s important to respect the following indications:
1. Before beginning, make sure the indoor unit is
not electrically powered.
2. Before installing the panel, pass the serial
communication cable through the specific
trunking, as far as the flush-mounting box.
3. Fix the panel to the flush-mounting box using the
screws supplied.
WARNING:
• To avoid electromagnetic disturbance,
remember to keep the serial communication
line separate from the unit power line
(minimum distance 20 cm).
• Use a shielded-conductor cable for the serial
line, to avoid the risk of disturbance.
