Color Description Functions
Secondary alternative
If there are 3 primary components in the illustration,
1 of the 3 components is this color.
Tertiary component
Special tool
Where the special tools or equipment are in an
illustration, they are this color.
Pressure gauges, specified tools
Parts that you move
A component that you must move, and that is not
necessary to remove from the machine.
Electrical wires, hydraulic hoses
Sections
Where a cross-section of a component is necessary,
this color shows the component that you see
through.
Engines, drivetrain
Channels
To show the flow of liquid in a channel.
Engines, drivetrain
Temperature
Where the temperature of liquid changes.
• Blue - Cold
• Red - Hot
Coolant flow, water flow
Pressure
Where the pressure or state of gas changes.
• Yellow - Low
• Orange - High
SCR system, hydraulic systems
