AGFA DR 100e - Page 104

All dimensions are in mm. Linear tolerances ±5 mm, angular ±1°.
Dimensions (in transport position)
width x length x height
700 x 1489 x 1504 mm
Handlebar height 932 mm
Weight 240 kg
(without DR detector)
Focus-floor distance (Z-axis)
444 mm - 2153 mm
Maximum height
2393 mm
104 | DR 100e (Digital Radiography) | Product Information
0365B EN 20181015 0853
