X-ray generator and X-ray tube assembly
Table 13: X-ray generator and X-ray tube assembly
Model name
Rotating anode monobloc MHF2030
High voltage generator
Thermo-tinned structure
Max. power (100 kV - 320
mA)
32 kW
Max. voltage to the tube 125 kV
Max. current to the tube 450 mA
Ripple to the max. power < 1%
Rise time to the max.
power
< 2 ms
Performance
According to the load curves of the x-ray tube
Housing
Min. inherent filtration
@75 kV
1.1 mm Al
Dimensions (W x D x H) 320 mm x 140 mm x
241 mm
324.5 mm x 145 mm x
244.5 mm
Weight 19.4 kg 18.7 kg
Thermal features
Thermal capacity 500 kJ 600 kJ
Thermal safety 60 °C ± 5° C
Thermal switch normally closed
Lung 0.16 dm
3
0.2 dm
3
Continuous thermal dissi-
pation
55 W 60 W
Max. housing tempera-
ture
60 °C
Heating curves (50 W, 100 W, 200 W, 300 W) and cooling curve (***)
