Connectivity
DR 100e requires a TCP/IP network to exchange information with a number of
other devices. The recommended minimum network performance is 100 Mbit
for wired ethernet and IEEE 802.11 g for wireless network.
Note: A wireless network operating on variable speed or subject to
interruptions will cause delays on the NX workstation.
DR 100e communicates with other devices in the hospital network using one
of the following protocols:
• DICOM
• IHE
DR 100e can be connected to a RIS system (input scheduling), a PACS system
(output image/data management) and to a hardcopy device (output image).
Connecting DR 100e to a wired network
To connect DX-D 100 to a wired network:
1. Place the unit in parking position.
2. Connect a network cable to the connector for the hospital network and
plug it into a network socket.
Figure 50: Wired network connector
Related Links
Connectors for the hospital network and for registering a DR Detector on page 29
DR 100e (Digital Radiography) | Product Information | 97
0365B EN 20181015 0853
