Labeling of the collimator
Figure 18: Example of type label
The type label is located at the rear side
of the collimator.
(A) Laser openings
(B) Warning labels
Avoid exposure.
Radiation is emitted from this opening.
(A) Laser radiation symbol
(B) Warning label:
LED Radiation
Risk group 2 IEC 62471:2006
CAUTION: Do not stare at operating light
source. May be harmful to the eyes.
(A) Laser radiation symbol
(B) Warning label:
Laser Radiation
Do not stare into beam
Class 2 LASER product
IEC 60825-1:2007
Po ≤ 1mW; λ = 645 ±10nm
42 | DR 100e (Digital Radiography) | Introduction
0365B EN 20181015 0853
