Collimator
Model R108 F
Collimation Manual with internal light source,
multilayer, squared field.
Assembly plan from focus 80 mm (3.14")
Coverage of the field at 100cm FFD
(SID)
minimum 0 cm x 0 cm
maximum 43 cm x 43 cm
Lighting source Clusters of high-brightness LED pow-
er
Lamp lighting time 30 s
Light intensity (IEC 60601-2-54) > 160 lux
Minimum contrast ratio (IEC
60601-2-54)
4:1
Focal distance measurement Retractable tape measure (maximum
extension 3 m)
Inherent filtration 2 mm equivalent Al at 75kV
Additional filtration
Manual selection
• 0 mm Al
• 1 mm Al + 0.1 mm Cu
• 1 mm Al + 0.2 mm Cu
• 2 mm Al
Rotation ± 120°
Weight 5.5 kg
Laser field to determine the focal dis-
tance at 1 m
112 | DR 100e (Digital Radiography) | Product Information
0365B EN 20181015 0853
