All dimensions are in mm. Linear tolerances ±5 mm, angular ±1°.
Dimensions (in transport position)
width x length x height
618 x 1366 x 1483 mm
Handle height 949 mm
Weight 170 kg
(without DR detector)
Focus-floor distance (Z-axis)
417 mm - 2092 mm
Maximum height
2333 mm
Rotation of the monobloc around the
arm axis (α swivel)
± 180°
Rotation of the monobloc around its
axis (γ swivel)
151° (102° ahead, 49° back)
106 | DR 100e (Digital Radiography) | Product Information
0365B EN 20181015 0853
