1.3 mm large focus 1.3 mm large focus
Nominal anodic power
(IEC 60613)
16 kW small focus
32 kW large focus
11 kW small focus
32 kW large focus
Anodic material
RT (Focus track: Tung-
sten-Rhenium),
TZM (Anode mass: mo-
lybdenum + titanium +
zirconium)
RTM
Anodic diameter 64 mm (2.52 inch)
Anodic angle 15°
Thermal capacity of the
anode
80 kJ (107 kHU)
Max continuous anode dis-
sipation
300 W
Min. inherent filtration
(IEC 522)
0.7 mm Al eq.
Tube material glass
Figure 55: X22 0.8/1.3
