HI ROLLER - BELT CONVEYORS 5. INSTALLATION
HI ROLLER, MINI ROLLER, LO ROLLER & HI LIFE 5.9. HAZARD MONITORING DEVICES
P115506 R3 65
STANDARD TAIL & TAKE-UP SECTION—NEW (Figure 5.40)
• The tail pulley alignment can be monitored with one surface mounted sensor
block installed near the top centerline of the tail pulley to detect a tail pulley
misalignment.
• The return belt alignment can be monitored with one rub block installed on
the bottom return belt in the space allowed in the take-up section, and will
detect a return belt misalignment.
Figure 5.40
