142 Agilent 1200 Preparative Pump User Manual
8 Parts and Materials for Maintenance
Hydraulic Path
Hydraulic Path
Tabl e 18 Hydraulic Path
Item Description Part Number
1 Tubing from solvent bottle, see “Solvent Cabinet and Solvent
Inlet Parts” on page 140)
G1361-60022
2, 3 Tube clip, Leak funnel 5042-6404, 5042-6405
4 Leak drainage, same as item 7 (re-order 5 m) 5062-2463
5 Prep Capillary 3 (basis kit), EMPV out to next module, SST 1/16”
o.d., 0.6 mm i.d., 400 mm long
G1361-67302
5a Prep Capillary 4, multi assembly to EMPV, SST 1/16” o.d.,
0.5 mm i.d., 160 mm long
G1361-67303
6 Tubing PTFE 0.057” i.d., EMPV to waste (re-order 5 m) 5062-2461
7 Corrugated waste tube, 120 cm (re-order 5 m) 5062-2463
8 Tubing, Seal wash pump to pump head 0890-1764
9 Tubing, Seal wash solvent bottle to seal wash pump 0890-1764
Tube adapter (for item 8 and 9) 5042-6422
10 Inlet ball valve, see “Pump-Head Assembly” on page 138
11 Outlet ball valve, see “Pump-Head Assembly” on page 138
12 Tubing, Seal wash to waste 0890-1764
13 Prep Capillary 1, Outlet valve 1 to multi assembly top, SST 1/16”
o.d., 0.6 mm i.d., 173 mm long
G1361-67300
14 Prep Capillary 2, Outlet valve 2 to multi assembly bottom, SST
1/16” o.d., 0.6 mm i.d., 178 mm long
G1361-67301
15 Prep Capillary 5 (gradient kit), Union to EMPV2 SST 1/16” o.d.,
0.6 mm i.d., 111 mm long
G1361-67304
16 Prep Capillary 6 (gradient kit), Union to mixer SST 1/16” o.d.,
0.6 mm i.d., 40 mm long
G1361-67305
