162 Agilent 1200 Preparative Pump User Manual
9 Configuring the Preparative Pump
Agilent 1200 Series Interfaces
RS-232C
The RS-232C connector is used to control the instrument from a computer
through RS-232C connection, using the appropriate software. The RS-232C
interface can be used for controlling the module with PCs running non-Agilent
Control Software. Most (but not all) of the Control Software products of other
manufacturers communicate via this RS-232C interface. If in such a scenario
the RS-232C interface cannot be used, the analog output connector can be
used instead, in which case an additional handheld controller (connected via
the CAN Connector) must be used.
The RS-232C connector can be configured with the configuration switch
module next to the GPIB connector. The RS-232C is designed as DCE (data
communication equipment) with a 9-pin male SUB-D type connector. The pins
are defined as:
Tabl e 26 RS-232C Connection Table (continued)
Pin Direction Function
1In DCD
2In RxD
3Out TxD
4 Out DTR
5Ground
6In DSR
7Out RTS
8In CTS
9In RI
