Main Power Supply Assembly
An over-temperature sensor in the main power supply is used to turn OFF
output voltages if the temperature exceeds the acceptable limit (for example, if
the cooling fan of the instrument fails). To reset the main power supply to
normal operating conditions, turn the instrument OFF, wait until it is
approximately at ambient temperature and turn the instrument on again.
The following table gives the specifications of the main power supply.
Tabl e 27 Main Power Supply Specifications
Maximum power 130 W Continuous output
Line input 100 – 240 volts AC ± 10%, line
frequency of 50/60 Hz
Wide ranging
Output 1 + 24 V / 4.5 A (maximum) Total power consumption of + 24 V
and + 36 V must not exceed 107 W.
Output 2 + 36 V / 2.5 A (maximum)
Output 3 + 5 V / 3 A
Output 4 + 15 V / 0.3 A
Output 5 - 15 V / 0.3 A
