Agilent Technologies 54830 Series Service Guide

Chapter 6: Replacing Assemblies
To remove and replace the bottom sleeve
6–7
9
Gentl
y lift the bottom sleeve up and out. Be careful to not catch the feet on the chassis.
Figure 6-3
Remove Bottom Sleeve
10 To replace the bottom sleeve, reverse the above procedure.
CAUTION PROPERLY TIGHTEN HANDLE AND SCREWS!
Torque the side handle and rear feet screws to 2 Nm (18 in-lb).
