Agilent Technologies 54830 Series Service Guide

Chapter 1: General Information
Specifications & characteristics
1–8
Specifications & characteristics
The following tables list the performance specifications and operating characteristics for the
Agilent Technologies 54830 Series oscilloscopes. Asterisks (*) denotes warranted specifications,
all others are typical. Specifications are valid after a 30 minute warm-up period, and within ± 5
°C from the self-calibration temperature.
Digital Acquisition
Analog Acquisition
Maximum Sample Rate 1 GSa/s
Memory Depth 4 M points/channel
Minimum Width Glitch Detection 2.5 ns
Maximum Sample Rate Real Time Full channel mode 2 GSa/s
Half channel mode 4 GSa/s
Maximum Effective Sample Rate Equivalent Time 250 GSa/s
Memory Depth Standard for B & D models Full Channel Mode 2 M points
Half Channel Mode 4 M points
Standard for A models Full Channel Mode 250 k points
Half Channel Mode 500 k points
With Option 040 Full Channel Mode 500 k points
Half Channel Mode 1 M points
With Option 080 Full Channel Mode 8 M points
Half Channel Mode 16 M points
Sampling Modes Real Time
Normal Successive single shot acquisitions.
Peak Detect Captures and displays narrow pulses
or glitches at all real time sample rates.
Hi Resolution Real-time boxcar averaging reduces
random noise and increases vertical
resolution.
Equivalent Time Random Repetitive sampling (higher
time resolution at fast sweep speeds).
Filters (Sin x)/x Interpolation: On/Off selectable FIR digital filter. Digital waveform
processing adds points between acquired data points to enhance
measurement accuracy and waveform display quality.
Averaging Selectable from 2 to 4096.
