Contents
Contents–1
1 G
eneral Information
Test equipment requirements 1-3
Accessories supplied 1-5
Options available 1-6
Accessories available 1-7
Specifications & characteristics 1-8
Agilent Technologies 54830 Series general characteristics 1-15
Recommended test equipment 1-17
2 Preparing for Use
To inspect package contents 2-3
To connect power 2-5
To connect the mouse, the keyboard, a LAN cable, a printer, and a GPIB cable 2-8
To connect oscilloscope probes 2-10
To connect the digital probe 2-12
Digital probe lead set 2-13
To tilt the oscilloscope upward for easier viewing 2-15
To turn on the oscilloscope 2-16
To turn off the oscilloscope 2-17
To verify basic oscilloscope operation 2-18
Installing application programs on Infiniium 2-19
Changing Windows System Settings 2-20
To clean the oscilloscope 2-21
3 Testing Performance
To test the dc calibrator 3-4
To test input resistance 3-6
To test voltage measurement accuracy 3-7
To test offset accuracy 3-11
To test bandwidth 3-13
To test time measurement accuracy 3-15
To test trigger sensitivity 3-22
To verify threshold accuracy 3-26
4 Calibrating and Adjusting
To run the self calibration 4-3
5 Troubleshooting
To install the fan safety shield 5-3
To troubleshoot the oscilloscope 5-4
Primary Trouble Isolation 5-6
No Display Trouble Isolation 5-10
Power Supply Trouble Isolation 5-11
To check probe power outputs 5-13
!
