Chapter 1: General Information
Agilent Technologies 54830 Series general characteristics
1–15
Agilent Technologies 54830 Series general characteristics
The Infiniium oscilloscopes meet the Agilent Technologies Environmental Specification (section
750) for class B-1 products with exceptions as described for temperature.
General Characteristics
Environmental Temperature Operating: 10°C to +40°C
Nonoperating: –40°C to 70°C
Indoor use only
Humidity Operating: Up to 95% relative humidity
(noncondensing) at +40°C
Nonoperating: Up to 90% relative
humidity at +65°C
Altitude Operating: Up to 4 600 meters
Nonoperating: Up to 15 300 meters
Vibration Operating: Random vibration 5-500 Hz,
10 minutes per axis, 0.3g (rms)
Nonoperating: Random vibration 5-500
Hz, 10 minutes per axis, 2.41g (rms)
Resonant search 5-500 Hz, swept sine,
1 octave/minute sweep rate, (0.75g),
5-minute resonant dwell at 4
resonances per axis.
Physical Size (excluding handle) Height: 216 mm
Width: 437 mm
Depth: 440 mm
Weight Net: approximately 20.5 kg
Power Line voltage selection None, PFC (Power Factor Correction)
Line voltage range 100-240VAC, ± 10% CAT II
Line frequency 47 to 440 Hz
Maximum power consumption 440 W
Safety Meets IEC1010-1 +A1, CSA certified to C22.2 No. 1010.1, Self certified to UL 3111.
