Chapter 2: Preparing for Use
To turn on the oscilloscope
2–16
To turn on the oscilloscope
1 Depress the power switch in the lower left-hand corner of the oscilloscope front panel.
Figure 2-14
Turning on the Oscilloscope
After a short initialization period, the oscilloscope display appears. The oscilloscope is ready to
use.
2 Hook up all cables and accessories before applying power. You can connect and
disconnect probes while the oscilloscope is turned on.
The first time that you turn on the oscilloscope, you may need to have a keyboard
and mouse connected. The keyboard and mouse are needed to enter the Product
Key from the Microsoft Certificate of Authenticity for Windows XP if prompted to
do so. This label is located on the rear panel of the Infiniium.
