Agilent Technologies 7010 Series User Manual

7 General Maintenance
To Disassemble the EI XTR Source
7000/7010 Series TQ GC/MS Operating Manual 169
Figure 53. Disassembling the EI XTR source
Table 16 Parts list for EI XTR source (Figure 53)
Item Description Part number
1 Setscrews G3870-20446
2 Screws G3870-20021
3 Source body G3870-20440
4 Extractor lens G3870-20444
5 Extractor lens insulator G3870-20445
6 Filaments G7005-60061
7 Spring washer 3050-1301
7 Flat washer 3050-0982
