Installation Guide
Connecting The Cabling
8
Connecting The Cabling
1. Connect the injector(s) to the GC. Use the tray cable, part number
G2614-60610, to connect the tray to the use GC. See Figure 7 or Figure 8.
Figure 7 7683 Automatic Liquid Sampler cabling for 6890 Plus
6890 Plus GC
G2613A
Injector
(Front)
G2613A
Injector
(Back)
Injector cables
Tray cable
G2614A
Tray
