The Configuration Screen
Use the Configuration screen to:

Set the GP-IB address of the instrument.

Perform a selftest.

Group the pulse parameters by timing and levels or by output 1/2 on
a two-channel instrument.

Select the frequency reference source and the frequency for the PLL.
To access the Configuration screen, press the CONFIG softkey. If the
softkey is not displayed, press MORE.
GP-IB Address
Set the Agilent 81110A or Agilent 81104A GP-IB address in the range of
0 to 30. The default address of both instruments is 10.
Perform Operation Selftest
Select S
ELFTEST
in the M
ODIFY
area.
Start the selftest by pressing ENTER. If the selftest fails, a flashing E is
displayed. Press H
ELP
to see the list of error messages.
10
TRG-LEV CONFIGMEMCARDLIMITS
