40
Getting Started
S
SS
Se
ee
ett
tttt
tti
ii
in
nn
ng
g g
g U
UU
Up a
p a p a
p a P
PP
Pu
uu
ul
ll
ls
ss
se
e e
e S
SS
Si
ii
ig
gg
gna
nana
nal
ll
l
P
PP
Pr
rr
ro
oo
og
gg
gr
rr
ra
aa
am
mm
mm
mm
mi
ii
ing
ng ng
ng
E
EE
Ex
xx
xa
aa
am
mm
mp
pp
pl
ll
le
ee
e
If you want to include this burst signal in your GP-IB program use the
following command lines. The comment lines starting with a # are not
required.
# Reset the instrument to start from a defined, default status.
*RST
# Switch off the automatic display update to increase programming
# speed.
:DISPlay OFF
# Pulse stream operating mode is required, but as we start from a
# default status it is not necessary to send a command for setting the
# instrument into pulse stream operating mode.
# Set the period to 20 ns, the pulse width to 10 ns, the leading edge to
# 3 ns and the trailing edge to 5 ns.
:PULSe:PERiod 20NS
:PULSe:WIDTh1 10NS
:PULSe:TRANsition1 3NS
:PULSe:TRANsition1:TRAiling:AUTO OFF
:PULSe:TRANsition1:TRAiling 5NS
N
NN
NO
OO
OTE
TETE
TE For Agilent 81110A with Agilent 81112A 3.8V/330 MHz output channel
installed the transitions can be selected either 800 ps or 1.6 ns. Leading
and trailing edge are equal.
# Set the amplitude to 3.3 Volts, the offset to 1.65 Volts.
:VOLTage1 3.3V
:VOLTage1:OFFSet 1.65V
# Enable the output 1 and the complement output 1 (Agilent 81110A
# with Agilent 81112A 3.8V/330 MHz output channel installed, only).
:OUTPut1 ON
:OUTPut1:COMPlement ON
