About this Book
This quick start guide helps you to quickly get familiar with the features
and the user interface of the Agilent 81110A Pulse Generator.
The information is valid for Agilent 81104A and Agilent 81110A. Where
required the differences are explicitly mentioned. Possible
configurations are:
Output Modules for 81104A Mainframe
Output Modules for 81110A Mainframe
As standard the instruments are equipped with one output channel.
Therefore, some of the described features will not be available on all
instruments.
Module Description Max Quantity
81105A 10V/ max.80 MHz Output Channel 2
Module Description Max Quantity
81111A 10V/ max. 165 MHz Output Channel 2
81112A 3.8V/ max. 330 MHz Output Channel 2
