Introducing the 81110A/81104A Pulse and Pattern Generators
W
WW
Wh
hh
ha
aa
at
t t
t y
yy
yo
oo
ou
u u
u c
cc
ca
aa
an
n n
n d
dd
do
o o
o w
ww
wi
ii
it
tt
th
h h
h t
tt
th
hh
he
e e
e 811
811811
8111
11
10
00
0A
AA
A/
//
/8
88
81
11
1104
104104
104A
AA
A
What you can do with the
81110A/81104A
This section introduces the basic features and use models of the
81110A/81104A Pulse and Pattern Generators.
Basic Features
The Pulse and Pattern Generators generate all standard pulses, digital
patterns and multi-level waveforms needed to test all current logic
technologies (such as TTL, CMOS, ECL, PECL, LVDS, GTL) and other
digital designs up to 330 MHz.
The instruments provide a reliable and wide range of signals, which can
be used in even more applications than its predecessor, the
Agilent 8110A. This is due to enhancements made in the feature set and
specifications of the Agilent 8110A. The glitch and drop out free varying
of any timing parameter and the timing calibration feature of the Agilent
81110A/81104A contribute to more accurate and confident
characterizations of the DUTs.
Benchtop Testing
The 81110A/81104A feature a graphic display showing all pulse
parameters at a glance. The cursor keys and the modify knob allow fast
and simple operation.
The user interface is designed to minimize the time invested in getting
familiar with the instrument. After familiarization, the instrument
supports quick setups of signals. This leaves you free to concentrate on
the measurement task and testing of the DUT.
