Chapter 2 2-81
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
23.Press .
24.After one sweep, press to normalize the
trace.
25.Press .
26.After one sweep, press to get a better viewing of the trace.
27.Press .
28.Write the marker 1 value (which appears on the analyzer display) on the performance
test record. This is the worst-case Test Port 1 input (receiver channel A) 2nd harmonic.
Test Port 1 Input Worst-Case 3rd Harmonic
29.To change the stop frequency for measuring the receiver 3rd harmonic:
If you do not have Option 006, press .
If you have Option 006, press .
30.Press .
31.After one sweep, press to normalize the
trace.
32.Press to get a better viewing of the trace.
33.Press .
34.After one sweep, press .
35.Press .
36.Write the marker 1 value on the performance test record.
37.Press .
Test Port 2 Input Worst-Case 2nd Harmonic
38.To set the stop frequency for measuring the 2nd harmonic:
If you do not have Option 006, press .
If you have Option 006, press .
39.Press .
40.After one sweep, press to normalize the
trace.
41.Press .
42.After one sweep, press to get a better viewing of the trace.
43.Press .
44.Write the marker 1 value (which appears on the analyzer display) on the performance
test record. This is the worst-case port 2 input (receiver channel B) 2nd harmonic.
Meas
→
System
Stop 1 G/n
Stop
G/n
System
→
Scale Ref
System
System
Stop 1.5 G/n
Stop
G/n
Meas
→
System
