Chapter 2 2-107
System Verification and Performance Tests
Agilent 8753ET System Verification and Performance Tests
12.The marker 1 (maximum) and marker 2 (minimum) readings should be within the
specified range for each power level with reference to the fixed marker value.
In Case of Difficulty
1. Ensure that the power meter and power sensor(s) are operating to specifications. Be
sure you set the power meter calibration factor for the range of frequencies that you are
testing.
2. Verify that there is power coming out of the analyzer’s reflection test port. Be sure you
did not accidentally switch off the analyzer’s internal source. If you did so, press
.
3. Repeat this performance test.
