Agilent Technologies 8720ES Service Guide

Chapter 2 2-73
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
Figure 2-40 Test Port Receiver Magnitude Compression Test Setup
Figure 2-41 Test Port Receiver Magnitude Compression for 75Ω Analyzers
2. On the analyzer, press .
3. Press .
4. Press
.
5. Press (or next CW frequency).
6. Set the step attenuator to 20 dB attenuation.
Preset
Avg
IF BW
10 x1
Meas
INPUT PORTS
B
Sweep Setup
SWEEP TYPE MENU
POWER SWEEP
Start −10 x1
Marker −10 x1
∆
MODE MENU
∆
REF = 1
Sweep Setup
CW FREQ
300
k/m
