Agilent Technologies 89410A Installation And Verification

Amplitude Accuracy (continued)
Measurement Lower Limit
(dBm)
Upper Limit
(dBm)
Measured Value
(dBm)
Pass/Fail
9.876 MHz, −30 dBm, Ch 2, 1 Mohm †
−0.5
0.5
9.876 MHz, −18 dBm, Ch 2, 1 Mohm †
−0.5
0.5
9.876 MHz, −6 dBm, Ch 2, 1 Mohm †
−0.5
0.5
9.876 MHz, 6 dBm, Ch 2, 1 Mohm †
−0.5
0.5
9.876MHz,18dBm,Ch2,1Mohm†
−0.5
0.5
49.234 kHz, −30 dBm, Ch 1, 50 ohm
−0.5
0.5
49.234 kHz, −18 dBm, Ch 1, 50 ohm
−0.5
0.5
49.234 kHz, −6dBm,Ch1,50ohm
−0.5
0.5
49.234 kHz, 6 dBm, Ch 1, 50 ohm
−0.5
0.5
49.234 kHz, 18 dBm, Ch 1, 50 ohm
−0.5
0.5
49.234 kHz, −30 dBm, Ch 1, 1 Mohm
−0.5
0.5
49.234 kHz, −18 dBm, Ch 1, 1 Mohm
−0.5
0.5
49.234 kHz, −6 dBm, Ch 1, 1 Mohm
−0.5
0.5
49.234 kHz, 6 dBm, Ch 1, 1 Mohm
−0.5
0.5
49.234 kHz, 18 dBm, Ch 1, 1 Mohm
−0.5
0.5
49.234 kHz, −30 dBm, Ch 2, 50 ohm †
−0.5
0.5
49.234 kHz, −18 dBm, Ch 2, 50 ohm †
−0.5
0.5
49.234 kHz, −6dBm,Ch2,50ohm†
−0.5
0.5
49.234 kHz, 6 dBm, Ch 2, 50 ohm †
−0.5
0.5
49.234 kHz, 18 dBm, Ch 2, 50 ohm †
−0.5
0.5
49.234 kHz, −30 dBm, Ch 2, 1 Mohm †
−0.5
0.5
49.234 kHz, −18 dBm, Ch 2, 1 Mohm †
−0.5
0.5
49.234 kHz, −6 dBm, Ch 2, 1 Mohm †
−0.5
0.5
† Option AY7 only
Serial Number:______________________Report Number:____________________
Agilent 89410A Verifying Specifications
Performance Test Record
3of14
