Agilent Technologies 89410A Installation And Verification

Amplitude Linearity
Measurement Lower Limit
(dB)
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
49.234 kHz, 6 dBm, Ch 2, 1 Mohm †
−0.5
0.5
49.234 kHz, 18 dBm, Ch 2, 1 Mohm †
−0.5
0.5
−10 dB, Ch 1
−0.1
0.1
−20 dB, Ch 1
−0.1
0.1
−30 dB, Ch 1
−0.1
0.1
−40 dB, Ch 1
−0.15
0.15
−50 dB, Ch 1
−0.15
0.15
−60 dB, Ch 1
−0.2
0.2
−70 dB, Ch 1
−0.2
0.2
−10 dB, Ch 2 †
−0.1
0.1
−20 dB, Ch 2 †
−0.1
0.1
−30 dB, Ch 2 †
−0.1
0.1
−40 dB, Ch 2 †
−0.15
0.15
−50 dB, Ch 2 †
−0.15
0.15
−60 dB, Ch 2 †
−0.2
0.2
−70 dB, Ch 2 †
−0.2
0.2
† Option AY7 only
Serial Number:______________________Report Number:____________________
Verifying Specifications Agilent 89410A
Performance Test Record
4of14
