AC Amplitude (high-impedance) Adjustment
Setup Nominal Signal
DC Level
22 +0.68 V Output of -24 dB range
23* -0.68 V Output of -24 dB range
24 +1.7 V Output of -16 dB range
25* -1.7 V Output of -16 dB range
26 +4.3 V Output of -8 dB range
27* -4.3 V Output of -8 dB range
28 +10.8 V Output of 0 dB range
29* -10.8 V Output of 0 dB range
30 +0.044V Output of -48 dB High DC range
31* -0.044V Output of -48 dB High DC range
32 +0.11 V Output of -40 dB High DC range
33* -0.11 V Output of -40 dB High DC range
34 +0.28 V Output of -32 dB High DC range
35* -0.28 V Output of -32 dB High DC range
36 +0.68 V Output of -24 dB High DC range
37* -0.68 V Output of -24 dB High DC range
* Constants are stored after completing this setup.
3. Using the numeric keypad or knob, adjust the displayed voltage at each setup to match the measured voltage.
Select ENTER VALUE.
4. After performing setup 37:
a. If your calibration procedures require you to verify this adjustment, exit the calibration menu and perform AC
Amplitude (high-impedance) Verification.
b. If you are making all of the adjustments and then verifying the instrument’s performance, continue with the
next procedure in this section.
