Agilent Technologies Agilent 3499A User Manual

187
Chapter 7 Plug-in Modules
N2262A 4 x 8 2-Wire Matrix Switch Module
4
7
N2262A Pinout P300 is a 96-pin male DIN connector mounted on the
N2262A. The connector and pinout assignments are shown below. Note
that the A and B rows in the connector are not used.
Pin # C Pin # C Pin # C Pin # C
1
COL0_L
9
Not used
17
Not used
25
COL4_L
2
COL0_H
10
ROW0_L
18
ROW2_L
26
COL4_H
3
COL1_L
11
ROW0_H
19
ROW2_H
27
COL5_L
4
COL1_H
12
Not used
20
Not used
28
COL5_H
5
COL2_L
13
Not used
21
Not used
29
COL6_L
6
COL2_H
14
ROW1_L
22
ROW3_L
30
COL6_H
7
COL3_L
15
ROW1_H
23
ROW3_H
31
COL7_L
8
COL3_H
16
Not used
24
Not used
32
COL7_H
C
B
A
32313029282726252423222120191817161514131211109876 54321
View from the Pin Side of the Connector
C
B
A
