Chapter 7 Plug-in Modules
44471A 10-Channel GP Relay Module
7
44471A Wiring Information
Use the Agilent 44481A Terminal Block to make connections to the
44471A. One 44481A is supplied with the module.
The terminal block includes a screw terminal that connects external
wiring to the 44471A. The screw terminal is shown below. Additional
information about the terminal block is given on page 285.
