Chapter 7 Plug-in Modules

44475A Breadboard Module

The 44475A circuit board is shown below.

Connection to screw terminal block (connector supplied)

Connection to backplane (connector supplied)

Backplane interface circuitry

(user supplied)

Component mounting area
