Plug-in Modules at a Glance
The Agilent 3499A/B/C mainframes support a variety of plug-in modules
to make test system configuration easy. Each module is described in
more detail later in this manual.
Multiplexer Modules
N2260A 40-Channel MUX Module (armature relays)
N2266A 40-Channel MUX Module (reed relays)
N2270A 10-Channel High Voltage MUX Module
44470A 10-Channel MUX Module
44470D 20-Channel MUX Module
General Purpose Relay Modules
N2261A 40-Channel GP Relay Module
N2267A 8-Channel High Current GP Module
44471A 10-Channel GP Relay Module
44471D 20-Channel GP Relay Module
44477A 7-Channel Form-C Relay Module
Matrix Modules
N2262A 4 x 8 Matrix Module
44473A 4 x 4 Matrix Module
High Frequency Switching Modules
N2268A 50Ω 3.5GHz Dual 4-to-1 MUX Module
N2272A 1 GHz RF 1-to-9 MUX Module
N2276A/B Dual 1-to-6 (4) Microwave MUX/Attenuator Module
44472A Dual 4-Channel VHF Switch Module
44478A/B 50Ω/75Ω 1.3 GHz Multiplexer
44476A 3-Channel 18 GHz Switch Module
44476B 2-Channel Microwave Switch Module
Optical Switch Modules
N2280A Optical Switch Quad 1-to-2 MUX Module
N2281A Optical Switch Dual 1-to-4 MUX Module
N2282A Optical Switch 1-to-8 MUX Module
Digital I/O Modules
N2263A 32-Bit Digital I/O Module
44474A 16-Bit Digital I/O Module
Multifunction/Special Purpose Modules
N2264A 12-Channel GP & 3-Channel High-current GP & 16-Bit Digital I/O
N2265A 4 x 4 Matrix & 16-Bit Digital I/O Module
44475A Breadboard Module
