254 Agilent 1200 Series Autosampler Reference Manual
8 Theory of Operation
Communication Settings for RS-232C Communication
The communication protocol used in this instrument supports only hardware
handshake (CTS/RTS).
Switches 1 in down and 2 in up position define that the RS-232C parameters
will be changed. Once the change has been completed, the instrument must be
powered up again in order to store the values in the non-volatile memory.
Use the following tables for selecting the setting which you want to use for
RS-232C communication. The number 0 means that the switch is down and 1
means that the switch is up.
Table 52 Communication Settings for RS-232C Communication
Mode
Select
12345678
RS-232C 0 1 Baud rate Data
Bits
Parity
Table 53 Baud Rate Settings
Switches Baud Rate Switches Baud Rate
345 345
0009600 1009600
0011200 10114400
0102400 11019200
0114800 11138400
Table 54 Data Bit Settings
Switch 6 Data Word Size
0 7 Bit Communication
1 8 Bit Communication
