Agilent 1200 Series Autosampler Reference Manual 117
Repairing the Autosampler 4
Stator Face
Frequency Poor injection-volume reproducibility
Leaking injection valve
Tools required 1/4 inch wrench (supplied in accessory kit)
Hex key, 9/64 inch (supplied in accessory kit)
Parts required Stator face 0100-1851 for G1329A
Stator face 0101-1268 for G2260A
Preparation Remove the front cover.
Remove the leak tubings (if necessary).
CAUTION
The stator face is held in place by the stator head. When removing the stator head,
ensure the stator face does not fall out of the valve.
1 Remove all capillary fittings from the injection-valve ports. 2 Loosen each fixing bolt two turns at a time. Remove the
bolts from the head.
