Agilent 1200 Series Autosampler Reference Manual 35
Installing the Autosampler 1
Sample Trays
Installing the Sample Tray
1 Open the front door.
2 Load the sample tray with sample vials as required.
3 Slide the sample tray into the autosampler so that the rear of the sample
tray is seated firmly against the rear of the sample-tray area.
4 Press the front of the sample tray down to secure the tray in the
autosampler.
NOTE
If the thermostatted autosampler tray pops out of position the air channel adapter is not
correctly inserted.
Figure 11 Installing the Sample Tray
