Agilent 1200 Series Autosampler Reference Manual 31
Installing the Autosampler 1
13 If an Agilent ChemStation is the controller, connect either
• The GPIB cable to the detector
• The LAN connector to the LAN interface
14 Connect the APG remote cable (optional) for non Agilent 1200 Series
instruments.
15 Turn ON power by pushing the button at the lower left hand side of the
sampler.
NOTE
The sampler is turned ON when the line power switch is pressed and the green indicator
lamp is illuminated. The detector is turned OFF when the line power switch is protruding
and the green light is OFF.
WARNING
To disconnect the sampler from the line, unplug the power cord. The power supply
still uses some power, even if the power switch at the front of the panel is turned
OFF.
WARNING
To avoid personal injury, keep fingers away from the needle area during
Autosampler operation. Do not attempt to insert or remove a vial or a plate when the
needle is positioned.
