Agilent 1100 Series Fraction Collectors User’s Guide 99
Specifications 5
Performance Specifications for the Fraction Collectors
maximum tube / plate
height
48 mm with long needle assembly G1367-87200
75 mm with short needle assembly G1364-87202
Maximum tube volume ca. 20 ml with 48 mm test tubes, ca. 30 ml with 75 mm test tubes or
unlimited, if funnels are used with external containers.
Maximum flow rate 10 ml / min (depending on viscosity and generated back pressure,
max. 6 bar at the diverter valve). The analytical scale fraction
collector can be modified for flow rates > 10 ml/min.
delay volumes [µl] Fraction collector inlet to diverter valve: ~50 (typical, depends on the
length of the tubing)
Diverter valve: ~15
Diverter valve to needle: ~10
Needle: ~4
delay calibration sensor Single wavelength absorbance detector working at 654 nm,
consisting of a LED and a photo diode
diverter valve 3/2 Diverter valve with low internal volume (15 µl), switching time
< 100 ms, maximum operating pressure 6 bar
cooling Optional (with additional G1330B), performance depending on
ambient conditions and the volume of collected fractions
maximum capacity 3 fraction collectors in parallel plus one recovery fraction collector
connected via 12-Position, 13-Port Selector valve (PN G1160A)
GLP features Early maintenance feedback (EMF), electronic records of
maintenance and errors
interfaces - Controller-area network (CAN).
- optional; LAN or external contacts interface
- RS232C,
- APG-remote (for remote start / stop signals to / from other
modules)
- Interface to G1330A Thermostat
- CAN-DC-out for operation of Agilent approved external devices like
valves
safety features Leak detection and safe leak handling, error detection and display,
exhaust fan for fume extraction of hazardous vapors
Tabl e 24 Performance Specifications Agilent 1100 Series ANALYTICAL SCALE Fraction
Collector (G1364C) (continued)
Type Specification
