7 Error Information
Pump Error Messages
1260 Infinity II Flexible Pump User Manual 142
Maximum stroke is too short
Error ID: 29203
The maximum stroke is too short.
During initialization the pump defines the operation position of the pump drives
and therefore the pistons. First the pump drive moves backwards to find a
mechanical stop within the ball screw. Afterwards, pistons move forwards for
finding the maximum available stroke volume. These values are expected within
a pre-defined range. "Maximum stroke too short" means that the outer drive
position is too close. This can be caused by a drive initialization without pump
head or if the pump head has not been installed properly (screws are loose).
• Parameter: 1 – 2 referring to pump drive
Pump drive stop not found
Error ID: 29207
The pump drive stop has not been found.
• Parameter: 1 – 2 referring to pump drive
Probable cause Suggested actions
1 Wiper shifted
Please contact your Agilent service
representative.
2 Pump head blocks piston movement
Replace, clean or repair pump head.
3 Pump drive motor is mechanically blocked.
Please contact your Agilent service
representative.
Probable cause Suggested actions
1 Pump drive spindle is defect.
Please contact your Agilent service
representative.
