1260 Infinity II Flexible Pump User Manual 221
8Maintenance
Install the Inline Filter
Install the Inline Filter
Tools required p/n Description
8710-0510 Open-end wrench 1/4 — 5/16 inch
Parts required # p/n Description
1 G7104-68000 Inline Filter Upgrade Kit
OR 1 G7131-68000 Inline Filter Upgrade Kit Bio-Compatible
Preparations
Turn the pump off.
1 Remove the capillary between ports 5 and 8 from the
Multipurpose Valve.
2 Clip the inline filter clamp to the Multipurpose Valve.
3 Connect the 90 mm capillary (part of the upgrade kit) to
the filter outlet.
4 Fix the inline filter to the clamp.
To Next Page
