Agilent Technologies G7104C User Manual

1260 Infinity II Flexible Pump User Manual 247
9 Parts and Materials for Maintenance
Multipurpose Valve (G7104C)
Multipurpose Valve (G7104C)
Item # p/n Description
1 5067-4237 Multipurpose Valve Head
1 3 1535-4857 Stator screws, 10/pk
2 1 5068-0001 Stator head
3 1 5068-0120 Stator ring
4 1 5068-0202 Rotor seal, Multipurpose Valve, PEEK, 1300 bar
5 1 1535-4045 Bearing ring
6 1 5068-0106 Spanner nut
7 1 5067-4106 Valve drive
8 1 Valve drive housing
(Contact SU)
9 1 G4204-40001 Valve Drive Holder
2 2200-0141 Screw for valve drive
1
2
3
4
6
5
7
8
9
