12 LAN Configuration
Dynamic Host Configuration Protocol (DHCP)
1260 Infinity II Flexible Pump User Manual 288
Setup (DHCP)
1 Note the MAC address of the LAN interface (provided with G1369C LAN
Interface Card or mainboard). This MAC address is on a label on the card or at
the rear of the mainboard, for example, 0030d3177321.
On the Local Controller the MAC address can be found under Details in the
LAN section.
Figure 34 LAN Setting on Instant Pilot
The DHCP functionality is available on all Agilent HPLC modules with on-board LAN Interface or LAN
Interface Card G1369C, and “B”-firmware (B.06.40 or above) or modules with "D"-firmware. All
modules should use latest firmware from the same set.
