1260 Infinity II Flexible Pump User Manual 15
1Introduction
Operating Principle
Figure 3 The hydraulic path (example of G7104A Flexible Pump installed with a G7167B
Multisampler)
Pump head
Inlet weaver
MCGV
Pressure sensor
Multisampler
Seal wash pump
Degasser
Seal wash sensor
Multipurpose
valve
Jet
Weaver
